Researchers have developed a 3D printed sensor worn on the ear that measures one of the most basic medical indicators of health in real time: core body temperature.
The ups and downs of core body temperature can signal a range of health conditions. The most obvious is an infection, which causes a fever. But temperature fluctuations can also indicate insomnia, fatigue, metabolic function, and depression. Current wearable sensors can detect skin temperature, but this can change depending on how hot or cold an environment is. And oral and other thermometers that measure core body temperature are designed only for periodic use and aren’t meant to be strapped on for constant detection.
The researchers integrated data processing circuits, a wireless module, and an infrared sensor, which detects ear (and thus core body) temperature, in a 3D printed device. The disk-like structure covers the ear and can be customized to fit the contours of a person’s ear for a comfortable fit. To ensure that users can still hear clearly while wearing the device, the researchers embedded a microphone to capture and transmit outside sounds to the inner ear. A Bluetooth module transmits temperature measurements to a custom smart phone app. Testing showed that the sensor measurements closely matched those of a commercial ear thermometer.
